| Item | Parameter |
| Sample Chamber Size | 320 × 480 × 130 mm (W × D × H) |
| Size of Host Machine | 330 × 580 × 360 mm (W × D × H) |
| Weight | 38.6 KG |
| Display Screen | 11.6-inch large capacitive touch screen |
| Detection Range | Al-U |
| Accuracy | ±0.03% (999 gold) |
| Test Object | Solid, Liquid, Powder |
| Tube Window | Glass window |
| Optical Structure | Vertical |
| Detector | Si-PIN detector |
| Collimator | Equipped with 2.5 mm collimator to reduce background noise, improve resolution and accuracy. |
| Camera | The built-in 5-megapixel HD CMOS color camera provides intuitive sample positioning and image recording functions while ensuring the X-ray accurately illuminates the target area, improving operation accuracy. |
| Language | Multiple languages including Chinese and English. |
| Power Supply | AC 220V ±5V, 50Hz (subject to change in different regions) |
| Algorithm | Adopts curve calibration method and fundamental parameter (FP) method to remove background differences, reduce errors, and improve test accuracy. |
| One-click Test Button | Place the sample → Close the top cover → One-click test → View the results. Simple operation suitable for non-technical users. |
| Data Printing | Bluetooth printer |
