| Item | EDX-N9 |
| Analytical Range | S - U |
| Test Items | 1. Heavy metals in RoHS Directive: Pb, Cd, Hg, Br, Cr 2. Halogens: Cl, Br 3. Eight heavy metals regulations: Pb, Cd, Hg, As, Cr, Sb, Se, Ba 4. Composition analysis of copper alloy, iron alloy, tin alloy, etc. 5. Electroplating layer thickness detection: Sn/Cu, Au/Ni/Cu, Zn/Fe, Cr/Fe, Ni/CuZn 6. Additional elements for Samsung system: Ni, Sn, etc. |
| Sample Type | Solid, Liquid, Powder |
| X-Ray Tube Life | ≥20,000 hours |
| Detector | Electrically cooled Si-PIN detector, 145±5 eV |
| Test Time | 60s - 300s (automatically adjusted by software) |
| Collimation System | Spot sizes: φ0.3mm, 1mm, 3mm, 5mm, 6mm, 8mm (automatically selected by software) |
| Camera Positioning | 8MP |
| Weight | 38 kg |
| Dimensions | 450mm × 400mm × 360mm (Sample chamber size: 450mm × 380mm × 85mm) |
| Environmental Range | Temperature: 15°C - 30°C, Humidity: ≤75% |
| Integrated Industrial Computer | Intel(R) i5 CPU, 8GB RAM, Windows 10 OS Humidi |
| Display | 22-inch monitor |
| Data Storage | 250GB (sufficient to store billions of data records) |
