| Product Parameters | |
| Type | Portable |
| Weight | 4.6KG(without battery) |
| Size | 200mm×200mm×268mm(L×W×H) |
| Sample Chamber Size | 170mm×130mm×60mm(L×W×H) |
| Detection Range | AI-U |
| Language | Multi languages including Chinese, English |
| Detector | PeDX G5:Si-Pin detector PeDX G7:SDD detector |
| Optical Structure | Oblique |
| Tube Window | Beryllium (Be) window |
| Collimator | Equipped with 1.5mm collimator to reduce background noise, improve resolution and accuracy |
| Accuracy | PeDX G5:±0.03% PeDX G7:±0.01% |
| Display System | 5.7-inch industrial-grade resistance touch screen Automatic display brightness adjustment according to environment |
| Computer Parameter | 1. MX 6 Quad, quad-core Cortex-A9 processor |
| Data Printing | Bluetooth printer |
| Data Transmission | Built-in 32G system memory, USB, Bluetooth |
| Algorithm | Adopts curve calibration method and fundamental parameter(FP) method to remove background difference, reduce error and improve test accuracy. |
| Camera | Built-in camera provides intuitive sample positioning and image recording function, ensuring accurate X-ray irradiation and operation |
PeDX precious metal analyzer is designed for quick and accu-rate analysis on precious metal compositions. It can conduct quick and accurate element analysis on gold, platinum, and palladium and other precious metals, providing results imme-diately
The device has the advantages of portability, high reliability, fast speed, non-destructive analysis, simple operation etc Light and compact design makes users bring conveniently to any tasting sites Outstanding configuration ensures accuracy and reliability of test results. Even non-pros can master the easy operation fast. It can meet high Industry standards for the jewelry showroom, factories and test agencies well.
Fast analysis Compared with traditional chemical methods, XRF precious metal analyzer provides results in seconds, greatly improving efficiency
High accuracy XRF technology provides relate purity and composition data with an accuracy up to 0.03% (999 gold).
Non-destructive analysis With ne need to pre-process samples, it is simple, convenient and fast to renke the non-destructive analysis of precious matak
Portability Small volume and light weight maka sary to carry and use in various environments
The software has a variety of built-in data processing and analysis took that can automatically proc analyse and generate reports on test data. Users can choose different output formats (eg, EXCEL, POE etc.) and can customise the content of the report to neet different test data management needs
